Working principle

SZGDouble-cone rotating vacuum Dryer double cone rotating tank, the tank in the vacuum state, to the jacket into a thermal oil or hot water heating, heat through the tank wall contact with the wet material contact. Evaporation of water vapor or other gases after wet material absorbs heat through the vacuum pump through the vacuum exhaust pipe is pumped. Since the tank body in a vacuum state, and the rotating of tank so that the material constant up and down, inside and outside the flip, it accelerated the drying rate of materials, improve drying rate, to achieve uniform drying purposes.

Feature

Double-cone rotating vacuum Dryer is a hybrid - drying in one of the new Dryer. The condenser, vacuum pump and supporting Dryer, vacuum drying device components. (Such as do not need solvent recovery condenser or may not) advanced design of this machine, the internal structure of simple, easy to clean, discharge all raw material, easy to operate.Can reduce labor intensity and improve the working environment. At the same time the rotation of container materials also rotated, but the wall does not plot material, so heat transfer coefficient, drying rate, not only save energy, but full uniform drying, good quality. It can be widely used in pharmaceutical, chemical, food, dye and other industries drying.

Applications

This machine is suitable for pharmaceutical, food, chemical and other industries powder, vacuum drying and mixing of granular materials, especially suitable for drying by the following

※We can not accept the high temperature heat-sensitive materials to be recovered material

※solvents and toxic gases

※easily oxidized, hazardous materials

※required for crystalline materials

※requires a very low residual volatile matter content material

Technical Specifications
